Galvanized Prefabricated Structural Steel Buildings for Food Processing Plant

Ask Lasest Price
Brand Name :	Ruly Steel
Model Number :	Ruly0418
Certification :	SGS, BV
Price :	USD29-USD99 Per Square Meter
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20000 Square Meter Per Month
Delivery Time :	30 Days

Add to Cart

Product Details
Company Profile

Galvanized Prefabricated Structural Steel Buildings for Food Processing Plant

Steel Structure Food Processing Plant/Galvanized Prefabricated Structural Steel Buildings

Prefabricated steel structure buildings are featured with high fire resistance,strong anti-corrosion ability. Steel structure warehouse mainly refers to the main bearing steel components including steel column,steel beam,steel structure,steel roof truss and all the parts with the welding ,bolt or rivet connection.
The roof and the wall panel can be made from composite panel or single sheet. The galvanized metal panel can prevent the rust and corrosion. The self-drilling bolts can make the connection between the panels tighter and prevent the leakage.The composite infill panel assembly can also be used for the roof and wall panel.The polystyrene,glass fiber,rock wool, polyurethane sandwich panel are all available.
The steel structure wall can also be supported by the brick wall. The applicable area include the large work plant or warehouse,super market,entertainment center and modular steel structure garage.

Main parts of the steel structures and technical parameters

Main Steel Frame System
Main structure	H section steel Q355, alkyd painting, two primary painting, two finish painting.
Roof purlin	XZ1606020*2.5, galvanized
Wall purlin	XZ1606020*2.5, galvanized
Intensive bolt	Grade 10.9
Turn buckle bolt	M20+2, steel Q235, processing
Anchor bolt	M24, steel Q235, processing
Ordinary bolt	Galvanized bolt M20
Ordinary bolt	Galvanized bolt M12
Brace nut	Galvanized bolt M12
Bracing System
Cross brace	Φ20 round steel bar Q235, process and painted (alkyd painting)
Angle brace	L50*5 angle steel Q235, process and painted (alkyd painting)
Column bracing	Φ25 round steel bar Q235, process and painted (alkyd painting)
Tie bar	Φ127*3 steel pipe Q235, process and painted (alkyd painting)
Batter brace	Φ32*2.5, Φ12 round steel bar Q235, process and painted (alkyd painting)
Wall & Roof System
Roof panel	75 mm PU sandwich panel
Wall panel	75 mm PU sandwich panel
Edge cover	0.5mm color plate, angle Alu.
Fittings & accessories	Nails, glue etc.
Unpowered ventilator	Diameter Φ600, stainless steel
Sky lighting band	1.2mm FRP, double layer
Sliding door	sandwich panel door
Roof drainage system
Gutter	0.5mm color steel plate
Rainspout pipes	Φ110 PVC pipe

Show drawings and designs

advantages

Advantages	1. Low cost and short construction period.
	2. Easy to assemble and disassemble with simple and common tools.
	3. High Durability and Easy to maintain. Could be used for over 50 years.
	4. Light weight, convenient for shipment and transportation.
	5. Good waterproof performance without extra facilities.
	6. Good fireproof performance with rock wool sandwich panel.
	7. Good performance of heat-insulation.
	8. Beautiful appearance, various colors and shapes for outer and inner roof panel and wall panel.
	9. Various designs available, customized designs acceptable.
Application field	Warehouse, Workshop, Plant, Farm, Carport, Metal shed, Hotel, House, Kiosk, Booth, Office, Sentry Box, Guard House, Shop, Toilet, Showroom, Villa, Logistic Building , Sports Building and so on.
