Prefabricated Steel Aircraft Hangars Large Space Metal Hangar
Design Steel Airplane Hangar
Steel structure materials in details:
1. Main structure: built up or hot rolled H beam.
2. Purlin: galvanized C purlin and Z purlin
3. Roof cladding: EPS / Rock wool /Fiber glass/PU sandwich panel or
corrugated steel sheet
4. Wall cladding: EPS / Rock wool /Fiber glass/PU sandwich panel or
corrugated steel sheet
5. Tie rod: circular steel tube
6. Wall or roof Brace: round bar or angel steel finish with hot
dipped galvanizing or anti rust primer paint
7. Column bracing and transverse brace: angle steel or H section
steel or steel pipe
8. Knee brace: angle steel
9. Roof ridge: corrugated steel sheet
10. Wrapping cover: color steel sheet
11. Roof gutter: color steel sheet, Galvanized steel sheet,
Aluminum sheet and stainless steel sheet
12. Rain spout: PVC pipe
13. Doors: sliding sandwich panel doors, rolling shutter door, high
speed shutter door or metal doors
14. Windows: PVC window, aluminum window or curtain glass wall
15. Connections: high strength bolts
16. Surface finishing: hot dipped galvanizing or anti rust primer
coating.
A cross-section of the hangar
Design details
| Specifications: |
| 1) Steel Framework (Q235B,Q355B) | 1.steel beam
2.steel column
3.bracing
4.The welded H shaped steel,the finished H type steel,hot rolling
type steel ,round pipe,round steel,square tube,etc. |
| 2) Wall and Roof | 1.single steel sheet 0.2mm-0.8mm thick
2.sandwich panel with EPS,PU,glass wool and rock
wool(50/75/100/120/150mm) |
| 3) Door | 1.rolling door
2.sliding door and flat open the door
3.steel sheet, aluminum-alloy,plastic steel
4.according to your requirements |
| 4) Window | 1.sliding window
2.plastic steel frame or aluminum frame
3.according to your requirements |
| 5) Gutter | 1.aluminum-zinc steel sheet
2.stainless sheet |
| 6) Downpipe | 1.pvc
2.stainless pipe |
| 7) Ventilation | 1.turbine vent
2.ridge vent
3.according to your requirements |
| 8) Other Materials | self-screwing tapping,bolt,nut ,foundation bolt ,pulling rivet etc. |
| Drawings & Quotation: |
| 1) Customized design is welcomed. |
| 2) In order to give you an exactly quotation and drawings, please
let us know length, width, eave height and local weather. We will
quote for you promptly. |
